First Flight!!!!

This entry was posted in Flying Maintenance N22UP on by

The first flight of N22UP was on the evening of June 13th out of KDMW in Westminster, Maryland. My planned flight was 45 min of basically engine break-in. I was fortunate enough to be assisted by Mike Bullock flying his RV-7 as a chase plane, and Mike Rollison running a ground safety vehicle.

I spent the day replacing access panels and doing another final inspection on the aircraft. I fueled up with 13 gallons per side and did some basic flight planning. My intent was to take off, climb to 4 or 5000 feet and basically orbit the airport at 25 squared for engine break-in. My transition training instructor, Bruce Bohannon, had really focused my attention on oil pressure and CHTs – so my goals was to make sure I had the former, and I managed the latter. I was expecting high CHTs due to initial engine break-in. Mike Bullock and I did a final walk around of the airplane, then we took a flight around the pattern in his plane to recon potential off field landing locations in the event of a low altitude engine failure. Once back on the ground, it was time to jump in the plane and take it flying.

I was cautious on takeoff – easing the power forward I kept it nice and straight. She shot down the runway and was airborne in no time. I pulled power back quite quickly and was in a rapid climb in no time. My engine temperatures stayed excellent throughout the flight. I did a little slow flight, a full flap power off stall, and then returned to the airport for a low pass followed by a long wheel landing.

Afterwards, review of the airplane reviewed the following squawks. There was some oil in the cowl. Some we suspect from the breather tube, but there also might be some leaking from the prop oil return line. The nose seal also might have a small leak. The propellor governor maximum rpm will need to be adjusted down. There is some rubbing of the cowl on the horizontal induction snorkel. All in all – a great first flight!

I will post more with engine data analysis later!

Video on Instagram

Airworthiness Inspection!

This entry was posted in Final Testing on by

Today was the big day. My DAR, Darrel Watson, arrived via his Kitfox at 9am. We also had an FAA ASI (Shaun) who needed to shoulder surf one of his inspections on site. Turns out that Shaun was also a Marine – and Darrel was Navy. Three veterans meant there was some good story telling on top of the very thorough inspection Darrel performed. Darrel noted that my build was one of the cleanest he’d ever inspected and noted in particular that my firewall forward and sheet metal work was well done. HIs comments were a huge confidence boost for me. Having built it, i’m aware of almost every ding, dent, and mistake!

We started out with paperwork, then moved to compliance – data plate, placards, log books and the like. With that out of the way Darrel started firewall forward with all of the engine controls and the moved to the rest of the aircraft.

All said and done, N22UP now has a special airworthiness certificate and is cleared hot to begin phase 1 flight testing. As a bonus my operating limitations allow me to do either the 40 hours or the task based flight testing. I plan to do the latter. I spent the remainder of the day putting inspection panels back on the aircraft and doing another inspection of my own as I went.

As a final note, I would definitely recommend Darrel as a choice of DAR. He was very cordial and helpful in working through the AWC application process. He did a thorough inspection – a good thing when you are looking to strap the plane on and take it flying!

Final Airworthiness Inspection Prep

This entry was posted in Final Testing on by

So I’ve not done a great job of taking photos over the past week, but much of what I have done has been small happy-to-glad type changes on the plane. And I’ve been inspecting things over and over again. Both for the purpose of the final Airworthiness Inspection with the DAR, but also for my first flight. My DAR noted that he has found a lot of inspections have had bolts of the incorrect size, so Mike and I went over the plane in detail and identified some marginal bolt length contenders. I set about rectifying these. Some could be fixed by switching from a standard washer to a thin washer. Others needed a slightly longer bolt size (and naturally an order to Aircraft Spruce!). I rectified all of those.

In the process of full head to toe inspection, I found a variety of small squawks. A couple adel clamps needed further tightening firewall forward. A couple electrical connections at the busses where loose. Mike found a small squeak in the airplane controls – a very slight rub of the control column at just the right spot required me to raise the control column just slightly. I also noticed that the stick to aileron bell cranks seemed off center. Upon inspection it was clear that despite having done the aileron neutralizing procedure with the bell crank jig more than once it was not perfectly set to neutral. My only guess as to how this could be was when things were apart the rod ends must have spun on one of the push rods. Either way. I disconnected the controls, used the jigs on the aileron bell cranks one final time and got everything perfectly neutral. I also did a small adjustment on the right flap.

I spent entirely too much time making myself some chocks out of spare aluminum angle. I’m very happy with the result, but it definitely took too much time!

Just a quick shot here of what the back seat passenger will see once I have an iPad mount. The iPad is able to connect to the G3X system via bluetooth and this provides synthetic vision and navigation information. A cheap way to provide instruments to the GIB!

My niece stopped by with her two daughters. We have some future aviators in the making!

I’ve almost fallen on my wing a couple times. I bought some skateboard grip tape off of amazon and cut to fit the wing walk area. This is just temporary, as I will put a different solution in place once the plane is painted. I’m planning to have an outline of the wing walk area painted, and then I will use clear skateboard grip tape within that outline. I don’t like the black grip tape applications. But for now, this grey wing walk grip tape will make sure no one falls.
